Isuzu 4BD1T Series Engine

isuzu4bd1 4BD1T

View

View

Isuzu 4BD1T Series Engine

Interview

Select the number of specifications

Please check the product information you want!

Product Detail

Engine:

Isuzu 3.9L4BD1-T(AKA QD100T)

Applications:

1986-1991 ISUZU NPR/Chevrolet W4500

Type:

4 stroke direct injection diesel

Configuration:

Inline 4 cylinder (I-4/L-4)

Displacement:

3.856 liters, 236.08 CID

Firing Order:

1-3-4-2

Engine Block:

Cast iron, dry type cylinder liner

Cylinder head:

Cast iron

Compression Ratio:

17.5:1

Cylinder Bore:

4.02 in (102 mm)

Cylinder Stroke:

4.65 in (118 mm)

valvetrain:

OHV,solid lifter camshaft

Injection:

Mechanical inline injection pump, direct injection

Aspiration:

Turbocharged, IHI 6HB6or Garrett T25 models

Engine Dimensions (approx):

Length: 31.3 in

Width: 27.8 in

Height: 29.7 in

Engine Weight(aporox):

~770 lbs

Peak Horsepower:

Up to 135 hp @ 3,000 RPM

(varies by application,135 hp rating common for Isuzu NPR/Chevrolet W4 applications)

Peak Torque:

Up to 243 Ib-ft @ 1,800 RPM(varies by application)

Idle Speed:

~650 RPM

Max Engine Speed:

-3,500 RPM

No comment
